Working with iptables

This is my notes, links and videos about iptables. Please, send me your informatio to upgrae the site.

Concepts of iptables:

  • Types of tables:
    • Filter: Contains the built in chains for inputs, forwards and outputs:
      • INPUT – packages destined for local sockets
      • FORWARD – packets routed through the system
      • OUTPUT – packets generated locally
    • Nat: is consulted when a packet tries to create a new connection.
      • PREROUTING – used for altering a packet as soon as it’s received
      • OUTPUT – used for altering locally generated packets
      • POSTROUTING – used for altering packets as they are about to go out
    • Mangle: used for packet altering:
      • PREROUTING – for altering incoming connections
      • OUTPUT – for altering locally generated  packets
      • INPUT – for incoming packets
      • POSTROUTING – for altering packets as they are about to go out
      • FORWARD – for packets routed through the box

IPTables Service

  • Installation (on Fedora): dnf install iptables-services
  • Start IPTables: systemctl start iptables-services
  • Enable IPTables (Start when the server boot): systemctl enable iptables-services

Manage all the rules

  • iptables -F |–flush <chain>: Flush or clear rules
  • iptables -Z |–zero <chain> <rule_number>: Reset packet and byte counters

Query the rules

  • iptables -L : List all the rules
  • iptables -L -v -n: List all the rules with packets and bytes managed
  • iptables -t nat -n -L -v: List all the rules with nat configuration

Add rules

  • Input Rules:
    • iptables -A  INPUT -s xxx.xxx.xxx.xxx -j DROP: Add a rule. (Block the access of IP)
    • iptables -A INPUT -p tcp -s xxx.xxx.xxx.xxx -j DROP: Block TCP traffic from that IP address. With -p option that specifies the protocol.
    • iptables -A INPUT -p tcp –dport xxx -j ACCEPT: Allow incoming connection on port xxx.
    • iptables -A INPUT -p tcp -m multiport –dports 22,80,443 -j ACCEPT: Allow input multiple port at once with -m multiport.
    • iptables -A INPUT -p tcp –dport 80 -m limit –limit 100/minute –limit-burst 200 -j ACCEPT: Limits the incoming connections from per minute to 100 and sets a limit burst to 200.
    • iptables -A INPUT -p icmp -i eth0 -j DROP: Block Incoming Ping Requests
    • iptables -I INPUT 1 -p tcp –dport 80 -j ACCEPT: Insert rules at a specific position. (After INPUT put the position)
    • iptables -A INPUT -j DROP: block all input traffic
  • Output Rules:
    • iptables -A OUTPUT -p tcp –dport xxx -j DROP: Block outgoing connections on a specific port use.
    • iptables -A OUTPUT -p tcp -m multiport –sports 22,80,443 -j ACCEPT: Allow output multiple port at once with -m multiport.
    • iptables -A OUTPUT -p tcp -d 192.168.100.0/24 –dport 22 -j ACCEPT: Limit certain connections on specific port to a given network.
  • Forwarding Rules:
    • iptables -t nat -A PREROUTING -i eth0 -p tcp –dport 25 -j REDIRECT –to-port 2525: Forward one service’s traffic to another port.

Modify the rules

  • iptables -R INPUT 1 -p tcp -s 192.168.0.0/24 –dport 80 -j ACCEPT: The command replaces the first rule.

Delete rules

  • iptables -D INPUT -s xxx.xxx.xxx.xxx -j DROP: Delete a rule.
  • iptables -D INPUT 5:  Delete the rule in the fifth position.
  • Disabling the firewall:
    • iptables -P INPUT ACCEPT
    • iptables -P OUTPUT ACCEPT
    • iptables -P FORWARD ACCEPT
    • iptables -F

Other tools/configurations

  • iptables-save > ~/iptables.rules: Save the rules
  • iptables-restore < ~/iptables.rules: Restore the rules
  • Enable IP Forwarding:
    • echo 1 > /proc/sys/net/ipv4/ip_forward
    • Permanent configuration:
      • Put net.ipv4.ip_forward = 1 on /etc/sysctl.conf
  • Log iptables:
    • iptables -A INPUT -i eth0 -j LOG –log-prefix “IPtables dropped packets:”: Log the dropped packets on the network interface eth0.
    • grep “IPtables dropped packets:” /var/log/messages: Review the log
    • iptables -I INPUT 5 -m limit –limit 5/min -j LOG –log-prefix “iptables denied: ” –log-level 7: Log dropped packets to syslog

Links

Books



Videos

Pending

Enjoy!!!
